Fixed Step Operator Platform
LTW’s height adjustable operator platforms allow people to effortlessly adjust to their perfect working height at large assembly lines or machinery!
With a lowered height of 8″ from the ground and a raised height of 16″, LTW’s Fixed Step Operator Platform helps increase productivity, safety, and work quality while reducing worker fatigue, time off the job, and injuries with industrial ergonomics.
Typical Price Range: $7,999—$13,199+
Customization and Discounts available. Request a quick quote today from an LTW Ergonomics Professional to find your price and other industrial ergonomic products in your budget!
OSHA-Compliant Ergonomics
The Fixed Step Platform is one of LTW’s industrial electrically height adjustable operator platforms that raises and lowers with the touch of a button.
In contrast with the Adjustable Steps Platform (Gen II), the Fixed Step staircase does not automatically adjust with the platform. Instead, the step remains in a fixed position, and the platform only raises a distance that is in alignment with OSHA standards for step height.
This platform is ideal for workplaces where the platform is crowded with other machinery or fixtures, and there’s no room for an adjustable staircase to move in and out.
Common Operator Platform Uses
Distribution Centers: Add operator height adjustability to order processing and shipment tasks.
Conveyors: Instead of adjusting your entire conveyor system, add height adjustability to the operator.
Machine Tending: Adjustable operator platforms enable operators to choose their perfect working height for loading and offloading parts from machinery.
Assembly Line Workstations: Height adjustment allows people to maintain proper working posture during repetitive assembly tasks.
Packing: Operators can customize their platform height to the packing station and what is being packed.
Multi-Shift Manufacturing Environments: Accommodate people of differing heights who work at the same station on different shifts.
Why is height adjustability important?
The task of making one workspace fit a diverse workforce is challenging, and can sometimes seem impossible. LTW helps companies like yours provide safe environments for all of their employees, particularly considering their physical differences.
LTW’s height adjustable Operator Platforms help organizations accommodate people of varying heights by allowing them to adjust their height to their work. This significantly benefits business and the people using the platforms through reduced worker fatigue and time off the job, increased productivity, and higher quality of work.
FAQ
Q: Who is the Fixed Step Operator Platform for?
A: The LTW Fixed Step Operator Platform is ideal for industrial workplaces that need a taller platform but don’t have room for the self-adjusting staircase that is included on the LTW Adjustable Steps Operator Platform. The platform raises 8″, compliant with OSHA standards for step distancing.
Q: I need something with different lowered and raised heights. What do you recommend?
A: See our Ultra Low Profile Operator Platform for a 2″ lowered height and 14″ raised height, without steps. If you want steps included, and taller heights, both the Fixed Step Operator Platform (current page) and Adjustable Steps Operator Platform can be customized to start at taller lowered heights at certain OSHA-compliant increments. Use the Request a Quote form at the bottom of any product page to get started!
Standard Features
- Single Step Staircase (Additional steps can be added for taller lower and raised heights, with customization from our robust in-house engineering team)
- Electric Actuator Motor Stroke: 8″
- Quiet Electric Screw Drive Lift System
- Soft Touch Button Motor Controller
- Lowered height: 8″
- Raised height: 16″ (8″ motor stroke)
- Dimensions: Customizable, from 48″ W x 36″D to 330″ W x 42″ D (increased sizing available with further customization)
- Side Guard Panels: Safety in Height Adjustment
- Welded Frame Construction: Heavy Duty 2″ x 7 Gauge Welded Square Tube Steel
- Floor Plate: 1/8″ Steel Plate with Optional Ergo Matting
- Floor Contact: Floor Levelers and/or 5″ Swivel Locking Casters
- Lift Capacity: 900lb Central Static Load Lift Capacity (Can be increased)
- Color: Powder Coated Matte Black & Golden Bronze (Optional Custom Colors)
- Shipped Assembled and ready to use!
LTW Fixed Step Platform seen on Briotix Health
Customizable Options
- Need platform options different from what is listed?
- Not a problem! Start by filling out the Quote Request Form below. In the “Additional Instructions,” write the general scope of your custom platform. An LTW Ergonomics Professional will reach out to you shortly to discuss the details.
Popular Customized Platform Sizes:
- 168″ W x 36″ D x 8″ H
- 126″ W x 36″ D x 8″ H
- 84″ W x 36″ D x 8″ H
- 60″ W x 36″ D x 8″ H
- 48″ W x 36″ D x 8″ H
- 168″ W x 42″ D x 8″ H
- 126″ W x 42″ D x 8″ H
- 84″ W x 42″ D x 8″ H
- 60″ W x 42″ D x 8″ H
- 48″ W x 36″ D x 8″ H
Platform & Pick2Cart™ Ergo System
In addition to individual products, LTW also offers integrated ergonomic systems. Included in the LTW Platform and Pick2Cart Ergo System are: Fixed Step Platform, Pick2Cart™, and Battery Charging Station. Quantities of items can be customized to your specific needs.
This Ergo System is made to work seamlessly with your large machinery. The height adjustable platform is positioned beside a large process or machine, and with just the touch of a button can be raised or lowered to the operator’s perfect working height for loading or unloading the machine.
Getting components to your machinery is just as ergonomic as loading. The industrial but lightweight LTW Pick2Cart™ allows operators to effortlessly pick parts or materials. It can then be pushed up to the platform, and adjusted in height to meet the platform operator’s perfect ergonomic height for component picking and loading. The Pick2Cart™ also features anti-collision Piezo technology to help protect against possible pinch points.
Popular Applications: injection molding, hydraulic presses, milling machines, CNC machines, conveyor lines
The Platform & Pick2Cart™ Ergo System in this video is specially made of unpainted stainless steel for cleanroom environments. LTW’s standard procedure is to powder coat all products, so please mention if you have special environmental features that require other options.
